Constant climate chamber with large temperature / humidity range 247 l series KBF-S Solid.Line

Choose another model
Constant climate chamber with large temperature / humidity range 247 l series KBF-S Solid.Line
Constant climate chamber with large temperature / humidity range 247 l series KBF-S Solid.Line Увеличить
Specifications
Interior volume: 247 l
Humidity range: 20…80 % RH
Temperature range: 0…70 °C
Inner dimensions: 650 x 485 x 785 mm
Housing dimensions: 925 х 800 х 1460 mm
Net weight: 172 kg

Manufacturer: Binder
All specifications

The new Solid.Line KBF-S climate chamber is a custom-made solution for long-term testing and accelerated stability testing for pharmaceutical products in accordance with the ICH Q1A guideline. The corrosion-free and condensation-free interior also ensures exceptionally stable temperature and moisture levels, even when fully loaded.

View full description
Constant climate chamber with large temperature / humidity range 247 l series KBF-S Solid.Line Zoom

The new Solid.Line KBF-S climate chamber is a custom-made solution for long-term testing and accelerated stability testing for pharmaceutical products in accordance with the ICH Q1A guideline. The corrosion-free and condensation-free interior also ensures exceptionally stable temperature and moisture levels, even when fully loaded.

Benefits
  • Homogeneous climate conditions thanks to APT.line™ preheating chamber
  • Standard-compliant testing according to ICH Q1A
  • Precise temperature and humidity control

Important characteristics
  • Temperature range: 0 °C to 70 °C
  • Humidity range: 20% to 80% RH
  • APT.line™ preheating chamber technology
  • Humidity regulation with capacitive humidity sensor and steam humidification
  • LCD to display temperature and humidity along with additional information and alarms
  • Internal data logger, measured values can be read out in open format via USB
  • Unit self-test for comprehensive status analysis
  • Inner chamber made completely of stainless steel
  • 2 stainless steel racks, incl. shelf supports
  • Access port with silicone plug, 30 mm, left
  • Robust twin casters with brakes, from 240 L
  • Class 3.1 independent temperature safety device (DIN 12880) with visual and audible temperature alarm
  • Computer interface: Ethernet
  • Independent water supply via tank
Manufacturer
Manufacturer Binder
Technical specifications
Humidity range 20…80 % RH
Temperature range 0…70 °C
Temperature variation at 40 °C 0.3 ± К
Maximum thermal compensation 300 W
Temperature fluctuation 0.1 ± К
Wall clearance sidewise 100 mm
Wall clearance back 100 mm
Load per rack 30 kg
Permitted load 100 kg
Sound-pressure level 52 dB(A)
Number of shelves (std./max.) 2/9
Energy consumption at 40 ° C and 75% rel. ow 400 Wh/h
Power rating 1.4 kW
Power parameters 220 V, 50 Hz, 1p
Housing dimensions 925 х 800 х 1460 mm
Inner dimensions 650 х 485 х 785 mm
Interior volume 247 l
Net weight 172 кг
