Swell Plate for CBR Swelling Test ua

Standards: EN 13286-47; ASTM D1183; AASHTO T193; BS 1377:4, 1924:2; NF P 94-078; AS 1289.6.1.1

Product Code

• UTS-0790 Adjustable Stem and Perforated Aluminum Plate for CBR Swelling Test
• UTS-0790A Adjustable Stem and Perforated Brass Plate, ASTM, for CBR Swelling Test
• UTS-0790NF Adjustable Stem and Perforated Plastic Plate, NF, for CBR Swelling Test
• UTS-0790AS Adjustable Stem and Perforated Plate, AS, for CBR Swelling Test
• UTS-0792A Tripod for CBR Swelling Test, ASTM, AS, for UTS-0700 and UTS-0740AS
• UTS-0792E Tripod for CBR Swelling Test, EN, for UTS-0612
• UTS-0792 Tripod for CBR Swelling Test, BS, NF, TS
• UTGM-0120 Analog Gauge 30 mm travel x 0.01 mm division
• UTGM-0148 Digital Dial Gauge 25x0,01 mm, LCD Display Data Output
• UTGM-0152 Digital Dial Gauge 12,7x0,001 mm, LCD Display Data Output
• UTS-0794 CBR Soaking Tank (6 pcs. CBR Mould Capacity )

This equipment is used to monitor the swelling by placing it on top of the soil sample. The swell test consists of perforated plate (swell plate) with adjustable stem, dial gauge and dial gauge tripod for mounting swell dial gauge in position on CBR Mould Collar.

The prefered gauge and each other equipment should be ordered separately for swelling test.
